PolyBrush™ Flexible Brushes

The brush of the future is here now.

PolyBrush was designed with the specific goal of providing a Brushlon alternative to customers who needed to replace their worn-out Brushlon mats. Polybrush is made to be the same height as Brushlon had been, making it so customers won’t have to modify machinery to install PolyBrush.

Designed & Manufactured by OPT Industries, Inc.
Developed in Partnership with The Industrial Brush Company, Inc.
PROD: PB044ZA-OG

PolyBrush Quote Form

Name(Required)
First Last
Company Name
Email Address(Required)
Phone
1.) What is PolyBrush being used for?(Required)
- Vibratory Feeders
- Vibratory Bowls
- Other
2.) What is the approximate size and weight of parts being moved?(Required)
3.) What best described the environment PolyBrush will be installed in?(Required)
- Dry (no coolant)
- Wet (water-based coolant)
- Wet (oil-based coolant)
4.) How will PolyBrush be installed?(Required)
- Hook and Loop Tape (Velcro)
- Glue or Epoxy
5.) What is the expected quantity needed and how often is it ordered?
Address(Required)
Street Address City State / Province / Region ZIP / Postal Code Country
Additional Comments
Comments
This field is for validation purposes and should be left unchanged.

Gentle, Non-Marking Vibratory Conveying Brush Surface

PolyBrush is the ideal replaceable brush mat for linear vibratory conveying surfaces. Sheets can be easily cut to size, facilitating usage in a variety of machines, as well as quick spot-replacement as needed. The 20° brush mat is suitable for minimum back pressure accumulation, transport-conveyors, and for sound and force dampening.

Easy to Use

Cut

Easily cut panels to size with band saw, box cutter, or razor. Makesure bristles are facing down!

Secure

PolyBrush panels can be secured with standard methods. We recommend using hook and loop tape for optimal performance.

Replace

Spot replace as needed without installing an entirely new panel.

Panel Size	6” W x 24” L x 0.25” H (0.19” trim) (trim length is similar to Brushlon 300 series height)
Weight Capacity	Recommended to run parts weighing 40g (1.41 oz) or less.
Temperature Capacity	PolyBrush should be kept below 55°C (131°F).
Solvents	Avoid prolonged contact with organic solvents and oil-based liquids. We recommend only using water-based coolants.

Trim length comparable to 3M’s Brushlon 331B and 321B series brush mats.

Cuts cleanly without risk of layer separation due to single material construction

30% bio-based materials sourced from conifer trees

Manufactured in Massachusetts, USA
